Latest from the Blog
FidoLight RGBW Spotlight: Update #5
I’ve been distracted on other projects, but now I’ve managed to follow through on everything I proposed in Update #4. The v4 revision of the FidoLight board is now just a 4-channel constant-current driver, and all the control functions are now moved to a very flexible Distributed Lighting Controller (DLC) board that can drive twoContinue reading “FidoLight RGBW Spotlight: Update #5”
FidoLight RGBW Spotlight: Update #4
I’ve now received the v3 revision of the FidoLight PCB boards, and initial testing is promising. As you can see in the photo below, I’m now using all SMT components, including the pin headers used to mount the Teensy 4 MCU. That will allow me to mount the board directly to the metal enclosure (i.e.Continue reading “FidoLight RGBW Spotlight: Update #4”
FidoLight RGBW Spotlight: Update #3
After a 2 month hiatus to focus on other projects, I now have some progress to report on. FidoLight Summary A compact 10W RGBW spotlight with an intelligent driver that can be controlled via a multi-drop/addressable RS-422 serial bus. The driver board supports high-level lighting effect commands such as Fade <to color> <duration> . MicrocontrollerContinue reading “FidoLight RGBW Spotlight: Update #3”
